| Specs |
| Network Protocols |
IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3x, IEEE 802.3af/at/bt, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1d, IEEE 802.1s, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1x |
| Gigabit Ethernet Ports |
8 |
| SFP+ 10Gigabit Ports |
2 |
| PoE Ports (PoE Models Only) |
8 |
| Total PoE Output (PoE Models Only) |
120W (30W per Port) |
| Total Non-Blocking Throughput |
28Gbps |
| Switching Capability |
56Gbps |
| Forwarding Rate |
41.644Mpps |
| Switching, Routing, and Multicast |
16K static, dynamic and filtering MAC addresses |
| 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN |
| VLAN virtual interface |
| GVRP (pending) |
| Spanning tree, 32 instances for STP/RSTP/MSTP |
| Static routing |
| Dynamic routing, including RIP, RIPng, OSPF and OSPFv3 |
| Policy routing (pending) |
| IGMP Snooping |
| MLD Snooping |
| MVR (pending) |
| Security |
User hierarchical management and password protection, HTTPS, SSH, Telnet |
| 802.1X authentication |
| AAA authentication including RADIUS, TACACS+ |
| Storm control |
| Port isolation, port security, sticky MAC |
| Filtering MAC address |
| IP source guard, DoS attack prevention, ARP inspection |
| DHCP Snooping |
| Loop protection including BPDU protection, root protection(pending) and loopback protection(pending) |
| Kensington Security Slot (Kensington Lock) support |
