Hikvision DS-UPS3000 – Description
UPS 3000VA / 1800W
Powerful 3000VA UPS Capacity:
The Hikvision DS-UPS3000 Oversea UPS is a high-capacity uninterruptible power supply designed to provide reliable backup power for critical electronic equipment. With a 3000VA / 1800W capacity, it can support CCTV systems, networking devices, computers, servers, and other essential equipment during power interruptions.
Wide Input Voltage Range:
The DS-UPS3000 accepts a wide 140 VAC to 290 VAC input voltage range, helping maintain stable operation when utility voltage fluctuates. Its 50/60 Hz self-adaptive input frequency makes it suitable for different electrical environments and applications.
Built-In AVR Voltage Regulation:
With built-in Automatic Voltage Regulation (AVR), this Hikvision UPS helps stabilize the supplied voltage without relying on battery power for every minor fluctuation. This feature is useful for protecting sensitive electronics from unstable electrical conditions.
Fast Power Transfer:
The UPS provides a transfer time of ≤10 ms, allowing connected devices to continue operating with minimal interruption when mains power fails. Its output voltage range is 210 VAC to 235 VAC, while the output frequency is 50/60 Hz ±0.5 Hz, depending on the operating configuration.
Reliable Battery Backup:
The DS-UPS3000 uses four 12V/9Ah lead-acid batteries and supports fast charging, recovering to approximately 90% capacity within 6–8 hours. Typical backup performance is rated at around 150 minutes at 100W, 15 minutes at 600W, and 6 minutes at 900W, although actual runtime varies with load and battery condition.
Multiple Protection Features:
Designed for dependable operation, the Hikvision DS-UPS3000 includes overload protection, short-circuit protection, surge protection, and discharge protection. These safeguards help reduce the risk of damage caused by electrical faults and excessive loads.
LCD Display and USB Interface:
An integrated LCD screen provides useful information including input voltage, output voltage, battery capacity, and load level. The USB communication port supports remote control and communication, making monitoring and management more convenient.
Compact and Practical Design:
Despite its high power capacity, the DS-UPS3000 has a practical footprint measuring approximately 412 × 145 × 210 mm and weighs around 18.5 kg. It operates within 0°C to 40°C and at 30%–90% non-condensing humidity, making it suitable for offices, security installations, and IT environments.
Ideal for Security and IT Equipment:
The Hikvision DS-UPS3000 is a practical choice for protecting CCTV surveillance systems, NVRs, networking equipment, computers, servers, and other critical electronics. Its combination of 3000VA capacity, AVR, battery backup, fast charging, LCD monitoring, USB communication, and comprehensive protection makes it a reliable power backup solution for demanding installations.
