HPE J9983A – HPE 1820 Switch 24G
J9983A Specifications |
|
| Device Type | Switch – 24 ports – managed |
| Interfaces | 12 x 10/100/1000 (PoE+) + 12 x 10/100/1000 + 2 x Fast Ethernet/Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| Enclosure Type | Desktop, rack-mountable, wall-mountable 1U |
| Subtype | Gigabit Ethernet |
| PoE Budget | 185 W |
| Throughput | up to 38.6 Mpps |
| Switching capacity | 52 Gbps |
| MAC Address Table Size | 8000 entries |
| Jumbo Frame Support | Yes |
| Processor | 400 MHz |
| RAM | 128 MB SDRAM |
| Flash Memory | 16 MB |
| Dimensions (W x D x H) | 17.4 in x 9.7 in x 1.7 in |
| Power Device | Internal power supply |
| Operating Temperature | 0°C to 50°C |
| Operating Humidity | 15% to 95% (non-condensing) |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Rack Mounting Kit | Included |
Additional information
| Access Ports | 24 |
|---|---|
| Access Ports Speed | 1 G (RJ-45) |
| Forwarding Rate (Throughput) | 38.68 Mpps |
| Management Platform | HPE Networking Instant On Cloud, Local Web GUI |
| Mounting Options | Rack Mount |
| POE | Not Support POE |
| Layer | Layer 2 |
| Switching Capacity | 52 Gbps |
| Uplink Ports | 2 |
| UpLinks Speed | 1G |
