Overview
The HPE Networking Instant On 1960 24p Gigabit 2p 10GBT 2p SFP+ Switch (JL806A) is a smart-managed, stackable Gigabit access switch with 24 copper ports and dual 10-Gigabit uplink options (10GBASE-T and SFP+). It is part of the Instant On 1960 Series, built for small and growing businesses that need high-bandwidth wired connectivity for IT, mobile, and cloud applications.
Key Features
- 24 RJ-45 autosensing 10/100/1000BASE-T ports plus 2x 10GBASE-T and 2x SFP+ 10GbE uplink ports
- Stacking capability for scalable network growth
- Layer 2+ features and cloud, mobile app, or local web GUI management
- No recurring subscription or licensing fees – included industry-leading limited lifetime warranty
Technical Specifications
| Specification | Details |
|---|---|
| Model | HPE Networking Instant On Switch 24p Gigabit 2p 10GBT 2p SFP+ 1960 (JL806A) |
| Ports | 24x RJ-45 autosensing 10/100/1000BASE-T ports; 2x SFP+ 10GbE ports; 2x RJ-45 autosensing 100/1000/10GBASE-T ports |
| PoE | None (non-PoE model) |
| Maximum standalone switching capacity | 128 Gbps |
| Maximum stacking capacity | 80 Gbps |
| Throughput | 95 Mpps |
| Latency | 100 Mb: <4.4 µs; 1000 Mb: <2.2 µs; 10G: <1.1 µs |
| MAC address table | 16,000 entries |
| Processor / memory | Single-core ARMv7 Cortex-A9 @ 800 MHz; 1 GB DDR3; 512 MB NAND flash; packet buffer 1.5 MB |
| Dimensions (D x W x H) | 13.79 x 17.42 x 1.73 in (35.05 x 44.25 x 4.395 cm) |
| Weight | 8.7 lb (3.9 kg) |
| Reliability (MTBF) | 123.0 years |
| Operating environment | 0-40°C, up to 10,000 ft |
| Management | Instant On Cloud; web browser; SNMP manager |
| Warranty | Instant On limited lifetime warranty and support |
Product Details
- Part of the HPE Networking Instant On Switch Series 1960 – a smart-managed, stackable family comprising 24- and 48-port access switches (with PoE and non-PoE variants), a 12-port multi-gig PoE switch, and a 16-port 10-Gigabit aggregation switch.
