J9982A
|
Feature |
Specification |
|
|---|---|---|
|
I/O ports and slots |
4 RJ-45 autosensing 10/100/1000 PoE+ ports; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only 4 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only |
|
|
Memory and processor |
ARM Cortex-A9 -400 MHz, 128MB SDRAM; Packet buffer size: 1.5MB, 16MB flash |
|
|
Performance |
100Mb Latency: <7 µs (LIFO 64-byte packets) 1000Mb Latency: <2.3 µs (LIFO 64-byte packets) Throughput: Up to 11.9 Mp/s (64-byte packets) Switching capacity: 16 Gb/s MAC address table size: 8000 entries |
|
|
Reliability |
MTBF (years): 112.36 |
|
|
Management |
Web browser |
|
Additional information
| Access Ports | 8 |
|---|---|
| Access Ports Speed | 1 G (RJ-45) |
| Forwarding Rate (Throughput) | 11.90 Mpps |
| Management Platform | Command line interface (CLI), HPE Networking Instant On Cloud, Local Web GUI |
| Mounting Options | Desktop, wall mount |
| POE | Support POE |
| POE Budget | less than 100 W |
| Layer | Layer 2 |
| Switching Capacity | 16 Gbps |
