Hikvision DS-3E1510P-SI – Description
8 Port Gigabit Smart PoE Switch
Reliable Gigabit PoE Networking:
The Hikvision DS-3E1510P-SI is an 8 Port Gigabit Smart PoE Switch designed to provide reliable network connectivity and efficient power delivery for IP cameras and other PoE devices. It features 8 Gigabit PoE ports and 2 Gigabit fiber optical ports, making it suitable for surveillance networks that require fast data transmission, flexible uplink connectivity, and centralized device management.
Powerful PoE Performance:
With support for IEEE 802.3af and IEEE 802.3at standards, the switch 8 port can deliver up to 30 W of power per PoE port. Its total PoE power budget reaches 110 W, providing sufficient capacity for multiple compatible IP cameras and network devices. The PoE ports use End-span power delivery through pins 1/2 (+) and 3/6 (-).
Up to 300 m Long-Range PoE:
The DS-3E1510P-SI supports long-range PoE transmission of up to 300 meters through Ports 1 to 8. This feature is particularly useful for surveillance installations where cameras are positioned far from the network switch. Actual long-range performance can vary depending on the camera model and cable condition.
Smart PoE Watchdog:
The built-in PoE Watchdog automatically detects cameras that become unresponsive and restarts them when necessary. This helps reduce manual maintenance and improves the reliability of surveillance systems by keeping connected cameras operational with minimal intervention.
Advanced Layer 2 Management:
This Hikvision smart PoE switch provides a range of Layer 2 management functions, including 802.1Q VLAN, STP, link aggregation, QoS, port rate limiting, and storm control. VLAN support allows network segmentation with configurable VLAN IDs from 1 to 4094, while static link aggregation supports up to 8 aggregation groups for improved bandwidth utilization and connection protection.
Network Security and Traffic Control:
Port isolation helps improve network security by preventing devices within an isolation group from communicating directly with each other while still allowing communication with external ports. QoS provides port-based priority configuration and supports SP and WRR scheduling modes, helping prioritize important network traffic.
Network Monitoring and Remote Management:
The Hikvision DS-3E1510P-SI switch 8 port supports network topology management, alarm push, and network health monitoring. Through Hik-Partner Pro, users can remotely monitor port rates, bandwidth utilization, PoE power usage, topology information, and alarm status. The platform also allows remote port and device restarting, long-range mode activation, and firmware upgrades.
Durable and Flexible Installation:
Built with a solid metal shell, the switch is designed for dependable operation in professional networking environments. Its compact dimensions of 217.60 × 27.80 × 108.55 mm and 1.21 kg net weight allow convenient desk-mounted or wall-mounted installation. It operates from 0°C to 40°C with 5% to 95% non-condensing humidity.
High-Speed Switching Capacity:
The switch provides a 20 Gbps switching capacity, 14.88 Mpps packet forwarding rate, 8K MAC address table, and 4.1 Mbits internal cache. These specifications help support smooth data communication across connected surveillance and networking devices.
Ideal for Surveillance Networks:
The Hikvision DS-3E1510P-SI is an excellent choice for CCTV installations, offices, commercial buildings, and other professional surveillance applications. Its Gigabit PoE connectivity, fiber uplinks, 110 W PoE budget, 300 m long-range transmission, PoE Watchdog, VLAN, QoS, and remote management features make it a versatile solution for modern IP camera networks.
